LOG 1.5 GHz radio link directive antenna

Description

LOG 1.5 GHz radio link directive antenna

LOG/1.5G – Technical parameters Frequency range 1100-1700 MHz
Polarization Horizontal or Vertical
Connector N female
Maximum power handling capability 300 W
Gain (at mid band, ref. to λ/2 dipole) 11.5 dBd
Impedance 50 ohm
Front to back ratio > 20 dB
Wind load (ref. 150 Km/h) 11 Kg (frontal) 9 Kg (lateral)
Grounding Via clamps
Horizontal Beamwidth (at -3 dB, at mid band) 22°
Vertical Beamwidth (at -3 dB, at mid band) 23°
Number of radiating elements 10 10
Material Aluminium
Pole Diameter 25-55 mm (others on request)
Dimensions (HxL) 1010×135 mm
